| Compatible film types | Microfiche; jackets; jumbo fiche; ultrafiche; microcards; 16/35 mm roll microfilm; cartridge (M-type, C-clip); aperture cards; photographic slides; negatives; 35 mm perforated films |
| Image sensor | 18 MP ultra-high resolution area array with real-time on-screen view |
| Lens Optics | Production-level, high-end customized lens developed specifically for microform clarity |
| Capture mode | Grayscale or bi-tonal |
| Capture time |
1/3 second per image |
| Reduction ratio |
7x to 60 |
| Scan area |
max. 35 mm x 47 mm / 1.38 x 1.85 inches (on film) |
| Output resolution | 100 – 2400 dpi |
| Scan options | Scan to file, CD/DVD, network, USB, print, email, Cloud, Google Docs, Dropbox |
| Focus adjustment | automatic and manual |
| Sensor optimization | included, fully adjustable optical image rotation |
| Zoom adjustment | motorized (optical) and digital |
| File formats | TIFF (raw, compressed, single or multi); PDF (single, multi-page); JPEG; JPEG 2000; BMP; GIF; PNG |
| Integrated USB output | Two built-in USB 3.0 ports / flash-drive ports (with backward compatibility) |
| Standard components |
Touchscreen-compatible software; manual and motorized roll film pods, smart edit |
| Scanner options | RapidScan Batch Scanning; OCR and Annotation, Vendor interface kit, 3M adapter, Opaque microcard LED |
| Light source | Custom-calibrated LED array |
| Security | integrated Kensington lock slot |
| Interface |
USB 3.0 |
| Operating system | Windows 7 Professional (64 bit only); Windows 8 (64 bit only) Intel Processor; WIN 10 PRO (64 bit), further alternatives on request |
| Dimensions | (w x d x h) 450 mm x 515 mm x 230 mm 17.7 x 20,3 x 9,1 inches |
| Work Space (Footprint) | (w x d) 305 x 515 mm /12 x 20.3 inches |
| Weight | 7.2 kg / 16 lbs |
